Concrete canvas – is a modern, cost-effective solution comparable in reliability and strength to reinforcement with concrete slabs. Unlike conventional concreting technology, it can be used in conditions with significant temperature fluctuations or in hard-to-reach areas.
The material makes it possible to create concrete structures without using mixing equipment. Due to its flexibility, it accommodates tight bends and takes the shape of any trench or embankment. The uncured canvas can be cut with hand tools.
Concrete canvas is available in 3 variants depending on the application: T5, T8 and T13, with thicknesses of 5 mm, 8 mm and 13 mm, respectively.
Used in transport and hydraulic engineering construction as waterproofing, reinforcement and erosion protection.
- Construction of trenches, channels and drainage systems
- Slope stabilization and protection
- Bunding
- Spillway installation
- Waterproofing of sludge pits
- Foundation preparation
- Ventilation channels
- Mine shaft bulkheads
- Vegetation suppression
- Gabion reinforcement
- Pipeline protection and drainage repair
- Cable covering/protection
- Resistance to hydrological loads and sudden temperature changes
- Waterproofing
- Chemical resistance to alkalis, acids, mineral oils and solvents
- Resistance to UV radiation
- Durability and crack resistance
- Non-combustibility
- Fast installation in all conditions
- Environmental safety
| Technical characteristics of concrete canvas, STO 56910145-025-2017 | |||
| Parameter | Value | ||
| T5 | T8 | T13 | |
| Material thickness at a pressure of 2 kPa, mm, min. | 5,0 | 8,0 | 13,0 |
| Areal density of concrete canvas, kg/m², ±15% | 7,0 | 12,0 | 19,0 |
| Tensile strength, kN/m, min. | 6,7/3,8 | 8,6/6,6 | 19,5/11,0 |
| Flexural strength, MPa, min. | 3,4 | ||
| Water resistance after 10 days | waterproof | ||
Buy TECHPOLYMER concrete canvas
"TECHPOLYMER" — a leading manufacturer of geosynthetic materials in Russia. We have been operating since 1994 and supply materials to leading companies, including Rosneft, Gazprom, Rosatom, Russian Railways and others. We undertake the full scope of work — from design to installation and commissioning.
We will help you select the type of concrete canvas to meet your requirements. We ship products in any volume throughout Russia and beyond its borders.
-
