Geomembrane: Type 1

ТУ 2246-001-56910145-2014, ГОСТ Р 56586-2015

Smooth polymer sheet providing waterproofing and protecting soil from chemicals up to hazard class 1.

Geomembrane: Type 1

The material is manufactured from virgin high-quality high-density polyethylene (HDPE) or linear low-density polyethylene (LLDPE) with stabilising additives. It offers high chemical resistance, flexibility, tensile and puncture strength, and complete watertightness. By request, the geomembrane can be manufactured in blue or white.

It provides complete sealing of the facility against exposure to waste products, including anthropogenic waste, up to and including Hazard Class I.

Advantages

Width — up to 5500 mm
Manufactured from virgin raw materials
100% waterproof
High tensile strength
Operating temperature range from plus 60 °C to minus 60 °C
Resistant to corrosion, rot and UV radiation
Environmentally safe
Service life — at least 50 years

Applications

Municipal solid waste (MSW) and industrial waste (IW) landfills
Oil production cluster sites
Road construction
Oil and gas pipelines
Tank farms and containment basins
Hydrometallurgical heap leaching sites
Sludge and tailings storage facilities
Toxic and radioactive waste repositories
Storage and emergency reservoirs
Dams, reservoirs and seepage barriers
Lagoons (manure storage facilities), silage pits and biogas reactors
Artificial water bodies and landscaping
Hydraulic engineering facilities
Underground structures

Technical specifications of geomembrane type 1, TU 2246-001-56910145-2014, GOST R 56586-2015
Parameter	HDPE
Nominal sheet thickness, mm	1.0	1.5	2.0	3.0
Standard roll size*, m	5*100	5*50	5*50	5*40
Tensile strength, min., kN/m	27	40	53	75
Elongation at break, min., %	700
Tear resistance, min., N	130	200	260	374
Puncture strength, min., N	400	550	640	960
Water permeability, water absorption	0
Vapour permeability	0
Operating temperature range, °С	from -60 to +60
UV resistance, min., %	90
* By agreement with the customer, sheets of other sizes may be manufactured
**Full geomembrane specifications are available upon request

Smooth geomembrane from the manufacturer

We are a leading geomembrane manufacturer in Russia. We have been operating since 1994 and supply materials to leading companies, including Rosneft, Gazprom, Rosatom, Russian Railways and others. We handle the full scope of work — from design to installation and commissioning.

The price of type 1 geomembrane depends on the material, volume and delivery geography. We ship products in any quantity throughout Russia and beyond.
